Model No.:44c0016
Brand:LIUGONG
Warranty:3 Month
Certification:ISO
Condition:New
Rated Load:3-6t
Transmission:Hydraulic - Mechanical
Load and Unload Mode:Front Discharge
Walking Mode:Wheeled
Type:Medium-sized Loader
Packaging:box
Productivity:10000
Transportation:Ocean,Land,Air
Place of Origin:CHINA
Supply Ability:1000 Pc per day
Certificate:ISO
Port:Shanghai,Qingdao,Guangzhou
Payment Type:L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm:FOB,CFR,CIF,EXW,FCA,CPT,CIP
Loader steering Hydraulic System: mechanical steering gear, hydraulic oil pump, distribution valve, oil tank, power Cylinder, relief valve and pressure limiting valve, etc. (1) When the steering wheel is not turned, the servo spool is in the neutral position, the hydraulic pump is unloaded at low pressure, and the steering hydraulic cylinder does not move. At this time, the vehicle drives along a straight line or a certain turning radius. (2) When turning the steering wheel to the right, the servo spool moves to the left, and the steering hydraulic cylinder has a rod cavity to enter oil, but no rod cavity to return oil. Because the piston rod of the hydraulic cylinder is fixed on the frame, the steering booster housing moves to the left following the spool, and the wheel turns to the right. At the same time, the position error between the servo spool and the steering booster housing is reduced, as long as it keeps rotating For the steering wheel, the position error will not be eliminated, and the steering wheel will rotate with the steering wheel. When the steering wheel stops rotating, due to the feedback effect, the position error between the servo spool and the steering booster housing is eliminated, and the position returns to the neutral position, the hydraulic pump is unloaded, and the steering stops. (3) When turning the steering wheel to the left, the working principle is the same but the direction is opposite
Product Categories : Home > Products > Transmission and converter System > Transmission Box
